Ekol Clarity Vision 5 Wood Burning Stove 62 x 60cm

Leg options
7 items left

Customer Reviews

Based on 13 reviews
69%
(9)
31%
(4)
0%
(0)
0%
(0)
0%
(0)
J
J.K.
Study Build - Large Glass - Order No.12467
P
P.H.
Great quality product

DEFRA Approved

This stove can burn wood in a Smoke Control Area (most towns and cities are Smoke Control Areas).

DEFRA Approved

This stove can burn wood in a Smoke Control Area (most towns and cities are Smoke Control Areas)

Eco Design 2022

This stove is certified as Ecodesign compliant (has passed the new and stringent 2022 regulations).

Ecodesign & myths about pollution

Eco Design 2022

This stove is certified as Ecodesign compliant (has passed the new and stringent 2022 regulations)

Ecodesign & myths about pollution

MATERIAL & Output

Material: Steel with a cast-iron door

Output: 5kW
(max approx: 5kW)

Material & Output

Material: Steel stove with a cast-iron door

Output: 5kW
(max approx: 5kW)

DImensions

Body
Width: 620mm
Height: 600mm
Depth: 281mm

Flue
5" (125mm)

Dimensions

Body
Width: 620mm
Height: 600mm
Depth: 281mm

Flue
5" (125mm)

KEY SELLING POINTS

Ultra-Clean Burning

82% Efficiency

Three air controls

Wide firebox and viewing area

Key Selling Points

Ultra-Clean Burning

82% Efficiency

Three air controls

Wide firebox and viewing area

Julian's Thoughts

Ekol were one of the first brands of stoves I sold, way back in 2013 in my small shop "The Wood Stove Hut". I have met the owners (Dorset based) many times and find them to extremely knowledgeable and professional. You cannot go wrong with Ekol, or their other brand, Saltfire.

Julian's Thoughts

Ekol were one of the first brands of stoves I sold, way back in 2013 in my small shop "The Wood Stove Hut". I have met the owners (Dorset based) many times and find them to extremely knowledgeable and professional. You cannot go wrong with Ekol, or their other brand, Saltfire.

Description

About the Ekol Clarity Vision 5

Image shows optional extra: burnished door. See "Customers Also Bought"

A contemporary steel stove that is excellent value for money.

Designed and developed in Dorset by Saltfire.

Three air-controls (primary, secondary and tertiary) so you are in control of your flame pattern and whatever the performance of your chimney you can be the boss.

Wood-only as standard but a multifuel kit is available as an optional extra (see "Customer's Also Bought").

Specifications

Output & Fuel

Wood-only as standard but a multifuel kit is available as an optional extra (see "Customer's Also Bought").
Nominal 5kW. Max. 6kW

This stove will run happily at 2-6kW depending on fuel load. Note that running the stove at a higher fuel level than that specified in the manufacturer's manual may cause degradation of stove innards (firebricks, baffle etc.) although these are replaceable (and repairable with beige fire cement).

What size stove do I need?


Eco Credentials

This stove meets and exceeds the new 2022 Ecodesign regulations

This stove is approved by DEFRA to burn wood in a Smoke Control Area


Efficiency

82% (as a rough guide 82% of heat goes to the room with 18% going up the chimney).

Don't overthink efficiency. 75%-85% is fine and90%+ efficiency may not work so well on shorter or difficult chimneys.


External Air

No, this stove cannot be fitted with an external air kit (draws air from outside via pipe direct to stove). Usually this option is not relevant unless a room air-vent is required and the property is airtight (by design or choice).

Air vent advice here


Body & Door

Steel stove (5-year body guarantee) with cast-iron door

What to buy steel or cast-iron? Do not overthink. Steel heats fast. Cast-iron takes a little longer but retains heat longer as fire dies.


Hearth

The Ekol Clarity Vision 5 stove can, if sited outside of a fireplace recess, be sited on a 12mm thick hearth.

If in a fireplace recess, a full 125mm thickness constructional hearth is required. This will usually be in place as part of the recess design.

Hearth regulation advice here

Dimensions

Dimensions

Height: 600mm
Width: 620mm
Depth: 2811mm
Front of pipe to rear of stove: 167mm

Flue outlet: 5" (125mm)

Which fitting pack for my liner? A fitting pack includes all you need except liner and chimney closure plate (also sometimes known as register plate)? Advice here


Glass

Viewing area (from outside stove looking in)

Width: 400mm
Height: 250mm


Flue

5" (125mm) collar top or rear (can be installed with a 5" or 6" chimney liner)

Top or rear connection


Air Gaps

Distance to combustibles SIDE: 800mm
Distance to combustibles REAR: 820mm

To non-combustibles there are no hard rules but, around the stove, a 50mm minimum air gap is recommended to brick/stone. This to be increased to 100mm for rendered or boarded surfaces. Prior to purchasing any stove download the installation manual to check that manufacturers do not have any additional requirements.

Distances & heat shield advice


Log Length

Maximum log length: 400mm

Delivery Promise

We offer 14 days from delivery to report any courier damage to your stove. If a stove is damaged by the courier we will replace or refund as desired.

Already have a chimney? You need 1. Stove 2. Liner 3. Fitting Pack 4. Chimney closure plate (Hardiebacker board from Builder's merchants or galvanised sheet).That's it!
No chimney? Check out our shed kits or let us design your clip-together chimney design - easy peasy.
