£595.00 (including VAT)
Hamlet Solution 5 Wood Burning Stove 2020 Series 4 Model 44 x 55cm × 1
Just had the stove fitted in a property in Newcastle under Lyme. We’re in a tall Edwardian building with a tricky chimney flue - or so I was informed by a local builder. Anyhow, no problems here and the 5inch liner went down a treat and connected to the bijou stove. We’ve put it in a room with only one external wall connected to the kitchen and the hall. Tall ceilings and around 4m square. First firing was in Saturday night and it took off really well. I wanted to buy something manufactured in Britain. I have Clearviews before, but they’re very pricey and couldn’t afford to repeat in this house , so I’m very pleased with this alternative. Good sized glass viewing window in the front which remained clear through burning and the stove produced more than enough heat for us. Controls are simple and straightforward too. The dog took up position in front of the stove, we opened a drink and the rest was silence. Thanks Stovefitters. A very good website and we’ll be back for act two in the New Year.
I found stovefitters site very easy to order from as I ordered every thing I needed in one go and got the delivery date I required,although I made a mistake with my delivery date, Arran was quick to change it so everything went smooth ,The Hamlet solution 5 is a great stove and the rest of the kit was as expected and good quality .Great after sales,Stovefitters were just a phone call away when I needed advice.#11679
This stove can burn wood in a Smoke Control Area (most towns and cities are Smoke Control Areas).
This stove can burn wood in a Smoke Control Area (most towns and cities are Smoke Control Areas)
This stove is certified as Ecodesign compliant (has passed the new and stringent 2022 regulations).
This stove is certified as Ecodesign compliant (has passed the new and stringent 2022 regulations)
Material: Steel with a cast-iron door
Output: 5kW
(max approx: 6.65kW)
Material: Steel with a cast-iron door
Output: 5kW
(max approx: 6.65kW)
Body
Width: 436mm
Height: 550mm
Depth: 387mm
Flue
5" (125mm)
Body
Width: 436mm
Height: 550mm
Depth: 387mm
Flue
5" (125mm)
Made in the UK
Good value
Installers like them
Made in the UK
Good value
Installers like them
Very solid and very British (Devon). The Hamlet is one of our top selling stove ranges. Ten year guarantee on the stove body shows how confident the brand is in its quality.
Very solid and very British (Devon). The Hamlet is one of our top selling stove ranges. Ten-year guarantee on the stove body shows how confident the brand is in its quality.
Replacing the Hamlet 5 SC this is the very latest version (Series 4) of the UK-manufactured (Devon) and very popular Hamlet Solution 5 with full SIA Ecodesign credentials and DEFRA-Approved to burn wood in a smoke control area (most cities and built-up areas).
The stove is multifuel as standard and is perfectly happy burning wood on its own or smokeless fuel.
A rear heatshield is available (see "Customer's Also Bought" on this page) allowing the stove to be placed closer to combustible materials.
An excellent ten-year guarantee on the stove body provides reassurance.
Other models in the range include the Solution 5 Compact and Solution 5 Widescreen.
Multifuel (can burn wood and smokeless fuel)
Nominal 5kW. Max. 6.65kW
This stove will run happily at 5kW depending on fuel load. Note that running the stove at a higher fuel level than that specified in the manufacturer's manual may cause degradation of stove innards (firebricks, baffle etc.) although these are replaceable (and repairable with beige fire cement).
This stove can burn wood and smokeless fuel/coal without any modification.
This stove meets and exceeds the new 2022 Ecodesign regulations
This stove is approved by DEFRA to burn wood in a Smoke Control Area
80.6% (as a rough guide 80.6% of heat goes to the room with 19.4% going up the chimney).
Don't overthink efficiency. 75%-85% is fine and90%+ efficiency may not work so well on shorter or difficult chimneys.
No, this stove cannot be fitted with an external air kit (draws air from outside via pipe direct to stove). Usually this option is not relevant unless a room air-vent is required and the property is airtight (by design or choice).
Steel stove (10-year body guarantee) with cast-iron door
What to buy steel or cast-iron? Do not overthink. Steel heats fast. Cast-iron takes a little longer but retains heat longer as fire dies.
This stove can, if sited outside of a fireplace recess, be sited on a 12mm thick hearth.
If in a fireplace recess, a full 125mm thickness constructional hearth is required. This will usually be in place as part of the recess design.
Height: 550mm
Width: 436mm
Depth: 387mm
Front of pipe to rear of stove: 144mm
Flue outlet: 5" (125mm)
Which fitting pack for my liner? A fitting pack includes all you need except liner and chimney closure plate (also sometimes known as register plate)? Advice here
Viewing area (from outside stove looking in)
Width: 27cm
Height: 26cm
5" (125mm) collar top or rear (can be installed with a 5" or 6" chimney liner)
Top or rear connection
Distance to combustibles SIDE: 550mm
Distance to combustibles REAR: 750mm (500mm with optional rear heat shield; 350mm if twin wall all the way to stove and heat shield).
You can find the optional heat shield in "Customer's Also Bought" on this product page.
To non-combustibles there are no hard rules but, around the stove, a 50mm minimum air gap is recommended to brick/stone. This to be increased to 100mm for rendered or boarded surfaces. Prior to purchasing any stove download the installation manual to check that manufacturers do not have any additional requirements.
Maximum Log Length: 300mm
We offer 14 days from delivery to report any courier damage to your stove. If a stove is damaged by the courier we will replace or refund as desired.
Already have a chimney? You need 1. Stove 2. Liner 3. Fitting Pack 4. Chimney closure plate (Hardiebacker board from Builder's merchants or galvanised sheet).That's it!
No chimney? Check out our shed kits or let us design your clip-together chimney design - easy peasy.
